Rutile-cellulosic coated general-purpose electrode for structural steelwork, workshop and maintenance welding, specially suited for vertical-down welding and tack-welds. Good gap bridging. Can be used on galvanized, primer painted and slightly
rusted parts. In assembly welding, this electrode can be used with the same current setting in all positions. Smooth, slightly concave welds blending into base metal without undercut. Slag in most cases self-releasing. Efficiency 100%.

Tabs

Спецификация

Classification
AWS A5.1:	E6013
EN 499:	E 42 0 RR 12
EN ISO 2560-A:	E 42 0 RR 12

Analysis of all-weld metal (Typical values in %)

C	Mn	Si	P	S	Cr	Ni	Mo	Nb	V	N	Cu
0.08	0.60	0.45	-	-	-	-	-	-	-	-	-

All-weld metal Mechanical Properties

Heat Treatment	Yield Strength N/mm2	Tensile trength N/mm2	Elongation A5 (%)	Impact Energy ISO - V (J) + 20 °C	Hardness
As Welded	> 420	500-640	> 22	> 60

Materials

S(P)235-S(P)355; GP240; GP280
